NorComp

689 SERIES
FEATURES: High density and reliability has made this connector a standard for the electronic industry. Both male and female have intermating bodies to prevent misalignment or mismatching. Male used on card edge with the female usually on the mother board. Available in 3 standard termination types. MATERIALS: Insulator: Glass-filled polyester. Contacts: Male pins - Brass. Female pins - Phosphor bronze. Plating: Gold flash in mating area, tin on solder tails. (Contact Beckwith Electronics for other plating options).	Euroconnector-DIN-41612 Straight

689 SERIES

FEATURES:

High density and reliability has made this connector a
standard for the electronic industry.

Both male and female have intermating bodies to prevent
misalignment or mismatching.

Male used on card edge with the female usually on the
mother board.

Available in 3 standard termination types.

MATERIALS:

Insulator: Glass-filled polyester.

Contacts:
Male pins - Brass.
Female pins - Phosphor bronze.

Plating: Gold flash in mating area, tin on solder tails.
(Contact Beckwith Electronics for other plating options).

Euroconnector-DIN-41612
Straight

Ordering Information

Position Part Numbers

DIP Solder IDC Wire-Wrap Strain Relief for IDC

96 Male 689-096-110-001 N/A 689-096-140-001 164-096-001-000

Female 689-096-210-001 689-096-290-001 689-096-240-001

Ordering Information
Position		Part Numbers
Position		DIP Solder	IDC	Wire-Wrap	Strain Relief for IDC
96	Male	689-096-110-001	N/A	689-096-140-001	164-096-001-000
96	Female	689-096-210-001	689-096-290-001	689-096-240-001	164-096-001-000
