D-SUB MINIATURE CONNECTORS
97 SERIES PANEL & CABLE MOUNT - SOLDER TYPE
Contact - Copper Alloy with Gold Plated on Nickel thermoplastic Insulator UL94/V-O Flame Retardant
Male - Plugs
Pins	Stock # Bulk	Std. Pkg. Bulk	Stock # Packaged	Twin Packed
9	40-9709M	50	40-9709MP	40-9709MTP
15	40-9715M	50	40-9715MP	40-9715MTP
25	40-9725M	50	40-9725MP	40-9725MTP
37	40-9737M	50	40-9737MP	40-9737MTP
50	40-9750M	50	40-9750MP	40-9750MTP
Female - Sockets
Pins	Stock # Bulk	Std. Pkg. Bulk	Stock # Packaged	Twin Packaged
9	40-9709S	50	40-9709SP	40-9709STP
15	40-9715S	50	40-9715SP	40-9715STP
25	40-9725S	50	40-9725SP	40-9725STP
37	40-9737S	50	40-9737SP	40-9737STP
50	40-9750S	50	40-9750SP	40-9750STP
95 SERIES - SOLDER TYPE Press Fitted, Tin Alloy on Nickel thermoplastic Insulator
Male - Plugs
Pins	Stock # Bulk	Std. Pkg. Bulk	Stock # Packaged
9	40-9509M	50	40-9509MP
15	40-9515M	50	40-9515MP
25	40-9525M	50	40-9525MP
Female - Sockets
Pins	Stock # Bulk	Std. Pkg. Bulk	Stock # Packaged
9	40-9509S	50	40-9509SP
15	40-9515S	50	40-9515SP
25	40-9525S	50	40-9525SP
98 SERIES PANEL & CABLE MOUNT - CRIMP TYPE Copper Alloy, Tabbed with Gold Plating on Nickel thermoplastic Insulator
Male - Plugs
Pins	Stock # Bulk	Std. Pkg. Bulk	Stock # Packaged	Twin Packed
9	40-9809M	50	40-9809MP	40-9809MTP
15	40-9815M	50	40-9815MP	40-9815MTP
25	40-9825M	50	40-9825MP	40-9825MTP
Female - Sockets
Pins	Stock # Bulk	Std. Pkg. Bulk	Stock # Packaged	Twin Packaged
9	40-9809S	50	40-9809SP	40-9809STP
15	40-9815S	50	40-9815SP	40-9815STP
25	40-9825S	50	40-9825P	40-9825STP
99 SERIES PANEL & CABLE MOUNT - CRIMP TYPE Press Fitted, Tin Alloy on Nickel thermoplastic Insulator
Male - Plugs
Pins	Stock # Bulk	Std. Pkg. Bulk	Stock # Packaged
9	40-9909M	50	40-9909MP
15	40-9915M	50	40-9915MP
25	40-9925M	50	40-9925MP
Female - Sockets
Pins	Stock # Bulk	Std. Pkg. Bulk	Stock # Packaged
9	40-9909S	50	40-9909SP
15	40-9915S	50	40-9915SP
25	40-9925S	50	40-9925SP

IDC CONNECTORS Discontinued for reference only
Metal Housing Assembly All Plastic - No Exposed Metal
Metal
Bulk Number	Number of Contacts	Packaged Number	Gender
40-8425M	25	40-8425MP	Male
40-8425S	25	40-8425SP	Female
Plastic
40-8309M	9	40-8309MP	Male
40-8309S	9	40-8309SP	Female
40-8315M	15	40-8315MP	Male
40-8315S	15	40-8315SP	Female
40-8325M	25	40-8325MP	Male
40-8325S	25	40-8325SP	Female

HIGH DENSITY D-SUB MINIATURE
PANEL & CABLE MOUNT - SOLDER TYPE
Male - Plugs
Pins	Stock # Bulk	Std. Pk. Bulk	Stock # Packaged
15	40-9515HDM	50	40-9515HDMP
26	40-9526HDM	50	40-9526HDMP
Female - Sockets
15	40-9515HDS	50	40-9515HDSP
26	40-9526HDS	50	40-9526HDSP
PANEL & CABLE MOUNT - CRIMP TYPE
Male - Plugs
Pins	Stock # Bulk	Std. Pk. Bulk	Stock # Packaged
15	40-9415HDM	50	40-9415HDMP
Female - Sockets
15	40-9415HDS	50	40-9415HDSP

98 & 99 SERIES PLUGS - SOCKETS & INSERTION TOOL
Plugs for 98 & 99 Series			40-9856MK - 5K per reel 40-9854MP - Pack of 25 40-9856M - Bulk 100 Pack
Insertion & Extraction Tool			40-9865 - Bulk 40-9865P - Packaged
Sockets for 98 & 99 Series			40-9866SK - 5K per reel 40-9864SP - Pack of 25 40-9866S - Bulk 100 Pack

HIGH DENSITY PLUGS - SOCKETS & INSERTION TOOL
A B C
Description	Packed	Figure	Packaged	Stock #
Male High Density Crimp Pin	100 per bag	A	40-9428MP	40-9428M
Female High Density Crimp Pin	100 per bag	B	40-9428FP	40-9428F
Insertion / Extraction Tool	1 Each	C	40-9427TP	40-9427T
